Horisontal milling machine T-type
CME
Type MB 3000 FLEX

Rotary table size 1.400 x1.400 mm
Max. table load 12T
Longitudinal travel (X) 3.000 mm
Vertical travel (Y) 2.000 mm
Cross travel (Z) 1.000 mm
Drill travel (W) 700 mm
Rotary table (B) 360 - 0,001 degree
Boring spindle dia. 150 mm
Spindle speed 50-2200 rpm
Spindle taper 50 ISO
Spindle motor power 30 kw
Ram size 580-430 mm
CNC Controller Heidenhain iTNC530

Accessories:
Cooling through spindle 60 bar
ATC 60 pots

Hours:
Spindle 27.048 hours

Machine dimensions:
Height 4.856 mm
Length 6.663 mm
Width 10.000 mm
Weight 70 T

Build year 2006
Robot
FANUC Robots
Type: M-710iC/50

Maximum reach 2.050 mm
Payload 50 kg
Load max (kg/lbs) 50 kg, J3 arm, 15 kg
Axes 6
Repeatability 0,07 mm
Installation Floor, angle, wall, ceiling
Robot
FANUC Robots
Type: M-710iC/50

Maximum reach 2.050 mm
Payload 50 kg
Load max (kg/lbs) 50 kg, J3 arm, 15 kg
Axes 6
Repeatability 0,07 mm
Installation Floor, angle, wall, ceiling

Robot
FANUC Robots
Type: M-710iC/50

Maximum reach 2.050 mm
Payload 50 kg
Load max (kg/lbs) 50 kg, J3 arm, 15 kg
Axes 6
Repeatability 0,07 mm
Installation Floor, angle, wall, ceiling

FMS
FASTEMS
Type: MLS-XHD

Load max pr. pallet 6.000 kg
Machine capacity 5 pcs
Pallet capacity 25 pcs
Available pallets 19 pcs
Loading stations 2 pcs
X 2650 mm max
Y 2300 mm max

Robot with grinding function 1 pcs
Layout dimensions 15 x 54 meter



Build year 2006
Horizontal Machining Centre with boring spindle Giddings & Lewis
Type:


Pallet size: 1.250 x 1.600 mm
Pallet load: 7.000 kg max.
Pallet change time: 55 sec.
Number of pallets 2 pcs
Table indexing: B-Axis 0.001°

Table cross travel (X) 3.000 mm
Spindle vertical travel (Y) 2.100 mm
Column longitudinal travel: Z 1.800 mm
Feed: X/Y/Z 1 – 40.000 mm/min.
Rapid: X/Y/Z 40 m/min

Rotary table 6 rpm
Max rotary diameter: Ø2.500 mm

Spindle taper: ISO 50
Spindle drive motor: 30 KW
Spindle speed: 20 – 5.000 rpm
ATC 120 pots
CNC controller: Siemens Sinumerik 840D
Max workpiece height: 2.000 mm


Accessories
Hexagon radio measuring probe
Loading stations 2 PCS

Build year 2001
Horizontal Machining Centre with boring spindle Giddings & Lewis
Type:


Pallet size: 1.250 x 1.600 mm
Pallet load: 7.000 kg max.
Pallet change time: 55 sec.
Number of pallets 2 pcs
Table indexing: B-Axis 0.001°

Table cross travel (X) 3.000 mm
Spindle vertical travel (Y) 2.100 mm
Column longitudinal travel: Z 1.800 mm
Feed: X/Y/Z 1 – 40.000 mm/min.
Rapid: X/Y/Z 40 m/min

Rotary table 6 rpm
Max rotary diameter: Ø2.500 mm

Spindle taper: ISO 50
Spindle drive motor: 30 KW
Spindle speed: 20 – 5.000 rpm
ATC 120 pots
CNC controller: Siemens Sinumerik 840D
Max workpiece height: 2.000 mm


Accessories
Hexagon radio measuring probe
Loading stations 2 PCS

Build year 2001
Horizontal Machining Centre with boring spindle Giddings & Lewis
Type:


Pallet size: 1.250 x 1.600 mm
Pallet load: 7.000 kg max.
Pallet change time: 55 sec.
Number of pallets 2 pcs
Table indexing: B-Axis 0.001°

Table cross travel (X) 3.000 mm
Spindle vertical travel (Y) 2.100 mm
Column longitudinal travel: Z 1.800 mm
Feed: X/Y/Z 1 – 40.000 mm/min.
Rapid: X/Y/Z 40 m/min

Rotary table 6 rpm
Max rotary diameter: Ø2.500 mm

Spindle taper: ISO 50
Spindle drive motor: 30 KW
Spindle speed: 20 – 5.000 rpm
ATC 120 pots
CNC controller: Siemens Sinumerik 840D
Max workpiece height: 2.000 mm


Accessories
Hexagon radio measuring probe
Loading stations 2 PCS

Build year 2001
Horizontal Machining Centre with boring spindle Giddings & Lewis
Type:


Pallet size: 1.250 x 1.600 mm
Pallet load: 7.000 kg max.
Pallet change time: 55 sec.
Number of pallets 2 pcs
Table indexing: B-Axis 0.001°

Table cross travel (X) 3.000 mm
Spindle vertical travel (Y) 2.100 mm
Column longitudinal travel: Z 1.800 mm
Feed: X/Y/Z 1 – 40.000 mm/min.
Rapid: X/Y/Z 40 m/min

Rotary table 6 rpm
Max rotary diameter: Ø2.500 mm

Spindle taper: ISO 50
Spindle drive motor: 30 KW
Spindle speed: 20 – 5.000 rpm
ATC 120 pots
CNC controller: Siemens Sinumerik 840D
Max workpiece height: 2.000 mm


Accessories
Hexagon radio measuring probe
Loading stations 2 PCS

Build year 2001
Horizontal Machining Centre with boring spindle Giddings & Lewis
Type:


Pallet size: 1.250 x 1.600 mm
Pallet load: 7.000 kg max.
Pallet change time: 55 sec.
Number of pallets 2 pcs
Table indexing: B-Axis 0.001°

Table cross travel (X) 3.000 mm
Spindle vertical travel (Y) 2.100 mm
Column longitudinal travel: Z 1.800 mm
Feed: X/Y/Z 1 – 40.000 mm/min.
Rapid: X/Y/Z 40 m/min

Rotary table 6 rpm
Max rotary diameter: Ø2.500 mm

Spindle taper: ISO 50
Spindle drive motor: 30 KW
Spindle speed: 20 – 5.000 rpm
ATC 120 pots
CNC controller: Siemens Sinumerik 840D
Max workpiece height: 2.000 mm


Accessories
Hexagon radio measuring probe
Loading stations 2 PCS

Build year 2001
Horizontal Machining Centre with Boring Spindle
Starrag Heckert 1
Type: HEC 1600 Athletic

Pallet size: 1250 x 1600 mm
Pallet load: max. 8.000 kg
Number of pallets: 25 pcs Fastems
Table indexing: B-Axis 0.001°

Table cross travel (X): 2.800 mm
Spindle vertical travel (Y): 2.200 mm
Column longitudinal travel (Z): 2.100 mm
Boring spindle axial travel (W): 740 mm
Feed X/Y/Z: 1 – 40.000 mm/min.
Rapid X/Y/Z: 40 m/min.
Rotaty table 8 rpm
Max rotary diameter 3.000 mm

Spindle taper: ISO 50
Spindle bearing diameter: 200 mm
Spindle drive motor: 37KW
Spindle speed: 20 – 2.500 rpm
Boring spindle diameter: 150 mm

ATC: 80 pots
CNC controller Siemens Sinumerik 840D

Hours
Spindle 21.400 hours
Accessories
Hexagon radio measuring probe
Coolant unit with vacuum rotation filtration system
High pressure coolant through spindle
Electrical clear view window Visiport.
Laser tool breakage control in working area.
Cylinder path interpolation
Tool and process monitoring ARTIS.


Machines without Fastems = without pallet changers.
- Pallet changer unit can be supplied by Starrag Heckert.

Build year 2007


Horizontal Machining Centre with Boring Spindle
Starrag Heckert 1
Type: HEC 1600 Athletic

Pallet size: 1250 x 1600 mm
Pallet load: max. 8.000 kg
Number of pallets: 25 pcs Fastems
Table indexing: B-Axis 0.001°

Table cross travel (X): 2.800 mm
Spindle vertical travel (Y): 2.200 mm
Column longitudinal travel (Z): 2.100 mm
Boring spindle axial travel (W): 740 mm
Feed X/Y/Z: 1 – 40.000 mm/min.
Rapid X/Y/Z: 40 m/min.
Rotaty table 8 rpm
Max rotary diameter 3.000 mm

Spindle taper: ISO 50
Spindle bearing diameter: 200 mm
Spindle drive motor: 37KW
Spindle speed: 20 – 2.500 rpm
Boring spindle diameter: 150 mm

ATC: 80 pots
CNC controller Siemens Sinumerik 840D

Hours
Spindle 21.400 hours
Accessories
Hexagon radio measuring probe
Coolant unit with vacuum rotation filtration system
High pressure coolant through spindle
Electrical clear view window Visiport.
Laser tool breakage control in working area.
Cylinder path interpolation
Tool and process monitoring ARTIS.


Machines without Fastems = without pallet changers.
- Pallet changer unit can be supplied by Starrag Heckert.

Build year 2007

Horizontal Machining Centre with boring spindle
Starrag Heckert 2
Type: HEC 1600 Athletic

Pallet size: 1250 x 1600 mm
Pallet load: max. 8.000 kg
Number of pallets: 25 pcs Fastems
Table indexing: B-Axis 0.001°

Table cross travel (X): 2.800 mm
Spindle vertical travel (Y): 2.200 mm
Column longitudinal travel (Z): 2.100 mm
Boring spindle axial travel (W): 740 mm
Feed X/Y/Z: 1 – 40.000 mm/min.
Rapid X/Y/Z: 40 m/min.
Rotaty table 8 rpm
Max rotary diameter 3.000 mm

Spindle taper: ISO 50
Spindle bearing diameter: 200 mm
Spindle drive motor: 37KW
Spindle speed: 20 – 2.500 rpm
Boring spindle diameter: 150 mm

ATC: 80 pots
CNC controller Siemens Sinumerik 840D

Hours:
Spindle 22.200 hours
Accessories
Hexagon radio measuring probe
Coolant unit with vacuum rotation filtration system
High pressure coolant through spindle
Electrical clear view window Visiport.
Laser tool breakage control in working area.
Cylinder path interpolation
Tool and process monitoring ARTIS.


Machines without Fastems = without pallet changers.
- Pallet changer unit can be supplied by Starrag Heckert.

Build year 2007

Vertical lathe machiningcenter with boring spindle
Dorries Scharmann
Type: VCE 2000/160
Pallet size: 1.600 mm
Pallet load: max. 8.000 kg
Number of pallets 13 pcs
Table indexing C-Axis 0.001°

Table cross travel (X) 2.300 mm
Column longitudinal travel (Z) 1.500 mm
Crossbeam positions: 9 steps off 100 mm
Feed X/Y/Z 1 – 6.000 mm/min.
Rapid X/Y/Z 8 m/min.

Max rotary diameter 2.000 mm
Max workpiece height 1.500 mm
Main Spindle
Spindle drive motor: 69KW
Spindle speed: 2.8 – 315 rpm
ATC for turning 59 pots - system 240.2

Live spindle – SK50
Spindle drive motor: 30KW
Spindle speed: 10 – 1500 rpm
ATC for SK50 61 pots

CNC controller Siemens Sinumerik 880M

Accessories
FMS 13 pallets
Rotary loading stations 2 pcs
Coolant unit with filtration system
Coolant through spindle

Machine weight Approx 40T.

Build year 1993

Vertical lathe machiningcenter
Dorries Scharmann
Type: VCE 2000/160
Pallet size: 1.600 mm
Pallet load: max. 8.000 kg
Number of pallets 13 pcs
Table indexing C-Axis 0.001°

Table cross travel (X) 2.300 mm
Column longitudinal travel (Z) 1.500 mm
Crossbeam positions: 9 steps off 100 mm
Feed X/Y/Z 1 – 6.000 mm/min.
Rapid X/Y/Z 8 m/min.

Max rotary diameter 2.000 mm
Max workpiece height 1.500 mm
Main Spindle
Spindle drive motor: 69KW
Spindle speed: 2.8 – 315 rpm
ATC 70 pots - system 240.2

Live spindle – SK50
Spindle drive motor: 30KW
Spindle speed: 10 – 1500 rpm

CNC controller Siemens Sinumerik 880M

Accessories
FMS 13 pallets
Rotary loading stations 2 pcs
Coolant unit with filtration system
Coolant through spindle

Machine weight Approx 40T.
Build year 1993
